You just purchased a Lockly Secure Smart Lock. Now we're going to help walk you through the installation process! Watch this video first and read through the step by step instructions below before installing, then follow it step-by-step so you don't miss anything.
Installation Manuals

User Manuals

1) Prep the door.
Installation Manuals - Prep the Door
Please review Step 1 of the Installation Manual and measure the door to make sure everything is correct.
 The ½ inch hole on the top is for stabilizing the lock. We have supplied 3M double sided tape to help secure your new lock in place. You do not need to drill a hole to secure the door, however, you can do so if you wish for extra security.  You can remove the pole by removing the pole counterclockwise with a flat head screwdriver.
Installation Manuals - Prep the Door II
2) Adjusting the Bolt
Installation Manuals - Adjusting the Bolt
The bolt can be adjusted depending on where the hole was drilled for your lock.  Make sure when you install the bolt all the way, the + sign in the middle of the hole. The bolt can be extended between 2 ¾ and 2 3/8” in order to fit your door.
Installation Manuals - Adjusting the Bolt II
3) Extending the Bolt
Installation Manuals - Extending the Bolt
Use a Philips screwdriver to turn clockwise and extend the bolt fully out as if a door was locked.  Make sure the THIS SIDE UP sticker is above the position of the + mark.  Use the supplied screws to secure the bolt in place into the door.
4) Preparing the Exterior Assembly
Installation Manuals - Preparing the Exterior Assembly
Assemble the pieces as shown in your instruction manual with the rubber piece securely attached to the back of the exterior piece of the lock.
5) Installing the Exterior Assembly
Installation Manuals - Installing the Exterior Assembly
Install the exterior assembly py passing the cable underneath the deadbolt and the torque blade through the + sign of the deadbolt.  When passing the torque blade through, make sure that the torque blade is passed through in the vertical position.  While this is all happening, it's critical to make sure your deadbolt is still fully extended.
Installation Manuals - Installing the Exterior Assembly II
Pass the cable through the hole of the metal plate supplied to mount the interior and secure the cable by passing it through the bottom and to the side.
Use the supplied screws to secure the lock on the bottom.
Installation Manuals - Installing the Exterior Assembly IIISecure the top if you have drilled a hole in your door with supplied screws, otherwise, you can attach the back plate with 3M tape (recommended).
Installation Manuals - Installing the Exterior Assembly IV
Make sure the lock is secured tightly by trying to move the lock with your hands, Use the supplied keys to turn the deadbolt to ensure the deadbolt is moving in a smooth operation.
Installation Manuals - Installing the Exterior Assembly V
6) Installing The Interior Assembly
Installation Manuals - Installing the Interior AssemblyInstall the cable by matching the Red side to the Red side marked on the interior lock and plug in securely.
Installation Manuals - Installing the Interior Assembly II
Make sure the thumb turn is vertical and you install the interior lock piece by sliding the torque blade into the lock vertically. If your torque blade is horizontal (left to right), remove the exterior piece of your lock and re-install vertically.
Installation Manuals - Installing the Interior Assembly III
7) Securing the Interior Lock
Secure the lock by installing the 2 screws located right below the batteries with the supplied screws.
Installation Manuals - Securing the Interior Lock
Before installing batteries, make sure your thumb turn is still facing vertically up, and your deadbolt is fully extended (locked position).
Installation Manuals - Securing the Interior Lock II
8) Installing Batteries
Install three batteries first.
Installation Manuals - Installing Batteries
Before putting in the 4th battery, press and hold the PROGRAM button while you install the 4th battery.
Installation Manuals - Installing Batteries II
You will hear a series of rapid beeps and you can let go of the PROGRAM button and the lock automatically programs itself for a right swing door or left swing door.
Installation Manuals - Installing Batteries III
Install the battery cover and secure it with Phillips screwdriver on the top.
 Installation Manuals - Installing Batteries IV
Test the lock by turning the thumb turn again and verify the deadbolt to move smoothly.
9) Installing Door Strike
Installation Manuals - Installing Door Strike
Install the door strike by screwing the screws to complete the installation. Close your door and make sure that the deadbolt will lock and unlock smoothly.
Congratulations, you're done! Now Install the Lockly App to set it up!
